Equipment in This Process
Equipment | Function |
Cattle Head Cleaning Device | High-pressure hot water cleaning with integrated tool disinfection |
Cattle Hoof Washing Machine | Mechanical friction + water flush for thorough hoof cleaning |
Key Features
Our cattle head cleaning device is used for cleaning skinned cattle heads, which is composed of a cattle head hook, a cleaning frame and a tool disinfection device. During cleaning, the operator can trim the cattle head with tools and rinse it with high-pressure hot water to ensure thorough cleaning. The used tools can be placed in the tool disinfection device for disinfection, ensuring the hygiene of the operation. The sewage in the device is discharged through the drain pipe at the bottom, and the cleaned cattle head can be taken down and put into the transport vehicle.
The cattle hoof washing machine, a core cattle by-product cleaning equipment, is used for cleaning skinned cattle hooves, which is composed of a transmission system, a spray system, a cleaning drum and a rotating disk. The surface of the rotating disk has protrusions, which increases the friction with the cattle hooves and improves the cleaning efficiency. Its structure and operation are basically the same as those of the beef tripe washing machine, which is easy to operate and efficient. Together with our cattle head cleaning device, it forms a complete set of head and hoof cleaning equipment, ensuring thorough cleaning of cattle by-products.
Technical Specifications — Cattle Hoof Washing Machine
Parameter | Value |
Drum Size | φ800 × 1,000 mm (typical) |
Loading Capacity | 30~50 kg/batch |
Washing Time | 4~5 minutes/batch |
Power | 1.5~2.2 kW |
Water Pressure | 0.2~0.4 MPa |
Technical Specifications — Cattle Head Cleaning Device
Parameter | Value |
Hook Load Capacity | ≥25 kg (single head) |
Disinfection Water Temperature | 82 ± 2℃ (auto恒温) |
Spray Pressure | 0.3~0.5 MPa (adjustable) |
Rinse Water Temperature | 40~60℃ (warm water) |
All head and hoof cleaning equipment of Henger Manufacturing complies with food hygiene standards, with reasonable structure and easy maintenance. We can provide customized equipment according to the customer's needs, and provide professional technical guidance and after-sales service.
Click to consult for detailed equipment parameters and quotes.
